| Model/Type | Slitter/Cutter/Creaser DC-746 |
|---|---|
| Document Size | Width: 210-370mm Length: 210-999.9mm *Max: 710mm with the feed tray and the exit tray |
| Document type/weight | 110-350g/m² (coated paper, high-quality paper, laminated paper, UV-coated paper) * Within the above paper weight range including laminate and coat layer *When using slitter module in slot 2 and/or slot 3: 127 gsm or more |
| Feeder tray capacity | 150mm *There is the load limitation for a document of over 670mm |
| Exit tray capacity | 150mm *Card stacker stacking height 90mm |
| Speed | Approx. 50 ppm (sheets/minutes), (A4 SEF, 2 cuts and 1 crease) *With registration mark on: approx. 40ppm. 3 steps adjustment |
| Processing accuracy | ±0.2mm |
| Minimum finishing size | Width 48mm Length 50mm |
| Maximum of Slit – Cut – Crease | Up to 6 slits, up to 30 cuts, up to 20 creases (On 1 document) |
| Margin slit width | 3.2 to 55 mm from the side edge |
| Margin gutter slit width | 5-15mm |
| Number of registered job programs | 250 jobs (Also PC via the PC controller) |
| Standard functions | Test feed, Air knife, Side blow, Feed skew adjustment, Ultrasonic double feed detection, Reject(Documents available:670 mm or shorter), Automatic job setup by reading barcode, Image drift compensation by reading Registration mark, End mark detection, Apply shrinkage, Job lock, Batch separation(Not available when IFS connected), Emergency stop, Inter lock all covers, Paper ejection conveyor, Slitter guide, Speed adjustments(3 levels), Gutter unit(2 units), Cleaning mode, Interval mode, Longitudinal magnification correction function, Vertical and horizontal position correction function, PDF template creator. |
| Compatible OS for PC controller | PC controller software (USB B type connector, PDF template creator) ・Windows 8.1 (32bit/64bit) ・Windows 10 (32bit/64bit) ・Windows 11 |
| Power supply | AC115V, 60Hz AC230V, 50/60Hz |
| Power consumption | 　　　　　Consumption Current　　Power 115V　　　5.2A　　　 550W 230V　　　2.7A　　　 550W Standby |
| Machine Size | In use (standard) 2,645 (W) x 870 (D) x 1,115 (H) mm In use (max document) 3,040 (W) x 1,020 (D) x 1,115 (H) mm When stored 1,890 (W) x 870 (D) x 1,115 (H) mm |
| Weight | 450kg |
| Optional equipment | Rotary tool module, Cross tool module, Optional slitter module, Center slitter module, . |
Slitter-Cutter-Creaser
DC-746 Slitter/Cutter/Creaser
DC-746 Slitter/Cutter/Creaser is a high speed automated finishing solution. The speed is 50 sheets/minute the fastest that even a large volume jobs can be finish easily and show excellent work efficiency. This model is capable of doing 6 slits, 30 cuts, 20 creases in one pass and more processes. Example:Perforation, Slit-score are possible by adding optional modules. It can create variety of products such as business cards, greeting cards, brochures, tickets, coupons, book covers and more.
| Process Speed |
|---|
| 50sheets per minute |
